Thermo-Lite Board® Product Line

Thermo-Lite Board® is a unique closed cell, lightweight composite product manufactured with cross-linked polymer foam and fiberglass, offering high specific strength and toughness. The non-absorbent material is extremely durable and dimensionally stable, provides an excellent bonding surface, has good impact strength, sound and thermal insulation, and is resistant to contamination and high temperatures. Offered in sheets or pre-cut parts/kits, Thermo-Lite Board® is built for lifetime performance and is ideal for endless applications subjected to static and dynamic loads.

Thermo-Lite Board® is manufactured in a thicknesses from .25" to 2", dimensions up to 60" wide and 144" long, and a density range of 9-46 lbs/ft³, depending upon the Product Line.

Please contact us for assistance to qualify a Product Line to meet your applications.

Thermo-Lite Board® CORE

Manufactured with polymer foam and a filter fiberglass lay-up, this product is a good coring material in niche applications. Available in a density range of 9 to 30 lbs/ft³ depending upon the thickness required. Ideally suited to as core material for a variety of lightweight sandwich structures, and compatible with a wide range of resins and adhesive processes.

Thermo-Lite Board® VERSATILE

Manufactured with polymer foam and a matt fiberglass lay-up, this product is a great choice for a wide variety of uses from floor to ceiling. Available in a density range of 12 to 40 lbs/ft³ depending on the thickness required.

Thermo-Lite Board® TOUGH-LITE

Manufactured with polymer foam and a medium-weight woven fiberglass lay-up, this product is acceptable for standard structural loading applications. Available in a density range of 18 to 24 lbs/ft³ depending upon the thickness required.

Thermo-Lite Board® TOUGH

Manufactured with polymer foam and a heavy-weight woven fiberglass lay-up, this product is acceptable for standard structural loading applications. Available in a density range of 24 to 44 lbs/ft³ depending upon the thickness required.

Thermo-Lite Board® SUPREME

Manufactured with polymer foam and an ultra-heavy weight woven fiberglass lay-up that offers superior mechanical properties, making it the ultimate product where the utmost specific structural strength is required. Available in a density range of 24 to 46 lbs/ft³ depending upon the thickness required.
